Industrial Aluminum Sawing Machine
Our Industrial Aluminum Sawing Machine is a heavy-duty, fully servo CNC automatic cutting solution engineered exclusively for mass processing all types of industrial aluminum extrusions. Integrating servo fixed-length feeding, hydro-pneumatic stable saw cutting, multi-angle mitre machining and intelligent automatic clamping, this all-in-one sawing equipment eliminates manual measuring, repeated clamping and secondary deburring procedures for curtain wall, window door, solar bracket and general industrial aluminum profile manufacturers. With ±0.05mm ultra-high positioning precision and burr-free cutting performance, it supports 24-hour uninterrupted heavy-load production, drastically lifting workshop throughput while lowering aluminum raw material waste and labor expenditure. Our LBL brand high quality hot sale machine models hold CE & ISO9001 certifications to meet import standards for European, Middle Eastern, Southeast Asian, Australian and American industrial buyers.
Send Inquiry
Product Description
Industrial Aluminum Sawing Machine Sepc.
|
Item |
Standard Industrial Aluminum Sawing Machine Parameters (Customizable) |
|
Model |
LBL-SAW455 /LBL-SAW500 /LBL-SAW550 |
|
Control System |
Full Servo CNC Automatic Control |
|
Standard Saw Blade Diameter |
Φ455mm / Φ500mm / Φ550mm |
|
Main Spindle Power |
5.5KW / 7.5KW High Speed Industrial Motor |
|
Adjustable Spindle Speed |
2000–3000rpm |
|
Max Feeding Cutting Length |
6500mm (Custom 3m–12m Available) |
|
Max Cutting Cross Section |
210mm Width × 320mm Height |
|
Standard Cutting Angle |
90°, ±45° Mitre Cut |
|
Optional Angle Range |
10°–170° Arbitrary Angle Adjustment |
|
Positioning Accuracy |
±0.05mm |
|
Repeated Cutting Tolerance |
≤±0.1mm |
|
Clamping Method |
Dual Vertical + Horizontal Pneumatic Clamps |
|
Working Air Pressure |
0.5–0.8MPa |
|
Cooling System |
Automatic Atomized Lubrication Circulation |
|
Factory Place |
Jinan City, Shandong Province, China |
|
International Certifications |
CE, ISO9001 |
|
Custom Voltage Support |
220V/380V/415V for Global Markets |
Industrial Aluminum Sawing Machine Standard Accessories Included
1. CNC servo feeding control system + 10-inch multi-language touch screen
2. Imported tungsten carbide aluminum cutting saw blade
3. Hydro-pneumatic damping saw head assembly
4. Double pneumatic anti-scratch clamping device
5. Automatic atomized cooling lubrication system
6. Full closed safety protective cabinet
7. Aluminum chip dust collection pipeline
8. Emergency stop & collision safety protection sensors
9. Complete English operation, maintenance manual & spare parts toolkit
FAQ
Q1: Are you a direct manufacturer or a trading company?
A: We are a direct professional manufacturer of window and door processing machinery with over 19 years of experience. Our own integrated factory ensures strict control of quality, delivery and cost, providing stable and reliable equipment globally.
Q2: What kind of after-sales support and warranty do you offer?
A: We provide a complete after-sales system: 12-month warranty, 24/7 online technical support, complete English documents, and long-term factory-price spare parts supply.
Q3: Can the machines be customized with our branding?
A: Yes, we offer OEM and branding customization. We can print your logo and brand name on the machine. Please provide your vector logo and requirements for accurate customization.
Q4: What is the typical lead time for production and shipment?
A: Standard machines (≤3 units): 15–20 working days; large/bespoke orders: about 30 working days. Exact time will be confirmed after receiving your official order.
Q5: Do you provide discounts for volume purchases or large projects?
A: Yes, we offer preferential pricing for bulk orders (≥5 units) or complete production lines. Contact our sales team for competitive quotes and flexible terms.
Q6: How do you ensure the quality of your machinery before delivery?
A: Strict quality control is applied: raw material inspection, precision testing during production/assembly, and full-performance test. Only qualified machines are shipped.
Q7: We see lower-priced options elsewhere. What justifies your pricing?
A: Our price lies in high-quality components, stable performance and long service life. It reduces failure and downtime, bringing higher efficiency and lower long-term costs.
Q8: What are your accepted payment terms?
A: We accept mainstream international payments (mainly T/T and L/C). Specific terms can be flexibly negotiated based on order value and cooperation mode.
